High Temperature Resistance PTFE Tube with Chemical Resistance and Self-Extinguishing Properties for Electronic Use

Name: High Temperature Resistance PTFE Tube with Chemical Resistance and Self-Extinguishing Properties for Electronic Use
Brand: Changzhou Longchuang Insulating Material Co., Ltd.
SKU: 10mm
Price: 0.05 USD
Availability: InStock

Nama Merek:	None
Nomor Model:	10mm
Moq:	1
harga:	negotiable
Ketentuan Pembayaran:	L/C,D/A,D/P,T/T,Western Union
Kemampuan pasokan:	10.000 meter hari

Informasi Rinci

Deskripsi produk

Informasi Rinci

Tempat asal:

Jangsu Cina

Sertifikasi:

ISO9001

Tahan Suhu:

-65 hingga 260C

Sifat mudah terbakar:

UL,VW-1

Isolasi:

Tinggi

Ketahanan Kimia:

tahan asam alkali

Warna:

Hitam, Merah, kuning, putih, biru, merah muda, ungu

Ketahanan aus:

0,05 hingga 0,10

Kemampuan memadamkan:

Padam sendiri

Listrik:

Ketahanan listrik yang tinggi

Kemasan rincian:

Karton

Menyediakan kemampuan:

10.000 meter hari

Menyoroti:

High temperature resistance PTFE tube

Chemical resistant PTFE tubing

Self-extinguishing PTFE tube electronics

Deskripsi produk

PTFE Non-Shrink Tubing

PTFE (Polytetrafluoroethylene) non-shrink tubing, also known as Teflon tubing, is a semi-rigid tube manufactured by extruding and sintering PTFE resin. It is non-heat-shrinkable (shrink temperature ≥ 320°C), maintaining stable dimensions under normal operating conditions.

Key Features

Temperature Range: -200°C to +260°C (continuous use)
Chemical Resistance: Resistant to almost all acids, alkalis, solvents, oxidizers (except fluorine, molten alkali metals)
Electrical Properties: High dielectric strength (≥55kV/mm), low dielectric constant (2.1), high volume resistivity (10¹⁸Ω·cm)
Low Friction: Lowest coefficient of friction among solids (≤0.04), non-stick, easy to clean
Mechanical: High strength, wear-resistant, creep-resistant, aging-resistant
Certifications: RoHS, REACH, FDA food contact compliant
Flammability: UL94 V-0 (self-extinguishing)

Specifications

Color: Natural translucent white, custom colors available
Voltage Ratings: 150V / 300V / 600V
Wall Thickness: Standard, thin, heavy
Sizes: Inner diameter 0.3mm ~ 20mm, custom available

Applications

Electronics: High-temperature wire harness, motor, transformer insulation
Chemical/Semiconductor: Corrosive fluid, high-purity chemical, specialty gas transport
Medical: Catheters, infusion tubes, steam sterilization lines
New Energy: EV battery coolant, high-voltage wire insulation
Aerospace: Extreme temperature, corrosion-resistant tubing
Food/Pharma: FDA-approved food transfer, sterilization line
